QCBOX  MODEL5

Number of inputs

4

DC over AC

± 20 V

Phantom power

0÷24V selectable

Number of I/O

6 OUT / 5 IN

Isense DC current

± 2,25 A

Connector

DB25

DC IN 3

± 2,5 V

Control interface

USB

DC IN 4

± 5 V

Dimensions

23 (w) x23 (d) x4 (h) cm

Output power

50W (8 Ohm)

Weight

1,4 kgf

THD (1 kHz)

0,004%

Power supply

150W 90 ÷ 240VAC

CLIO

24 Bit sigma-delta D/A Converter

Input range

+40 ÷ -40dBV

Frequency range

1Hz-45kHz

Input impedance

64kOhm (5.6kOhm mic)

Frequency accuracy

better than 0.01%

Phantom power

8.2V

Frequency resolution

0.01Hz

Connections

analog RCA in and out

Output impedance

150Ohm

Dimensions

9(w)x12(d)x2.5(h)cm

Max output level

13dBu (3.46Vrms)

Weight

0.3 kgf

Attenuation

0.1 dB steps to full mute

Power supply

USB powered (480 mA)
